PERFAIR-CT High Performance Plenum for Round Diffusers, Top Connection
PERFAIR-CT High Performance Plenum for Round Diffusers, Top ConnectionNEX-C Painted Grey with Night Elements and PERFAIR-CT Exposed DuctNEX-C Painted Black With Conical Plenum Exposed Duct Restaurant

PERFAIR-CT

0 Reviews

Conical Plenum for Round Diffusers, Top Connection



PERFAIR-CT conical plenum with top connection for AXO, NEX, OTO and PLAY round diffusers. With built-in perforated damper + air equalizer, or choice of cable-operated dampers. Includes anti-seismic tabs and crossbar with long screw and white cap for face attachment.

Ideal for open ceilings with apparent duct.

For 24.5″ face diameters, with choice of 6″, 8″, 10″ or 12″ neck diameter.

Made by EffectiV.

Product Description

PERFAIR-CT conical plenum with top connection for AXO, NEX, OTO and PLAY round diffusers. With built-in perforated damper + air equalizer, or choice of cable-operated dampers. Includes anti-seismic tabs and crossbar with long screw and white cap for face attachment.

Ideal for open ceilings with apparent duct.

For 24.5″ face diameters, with choice of 6″, 8″, 10″ or 12″ neck diameter.

Made by EffectiV.

Documents

Additional Information

Dimensions

06″ Neck Diameter, 08″ Neck Diameter, 10″ Neck Diameter, 12″ Neck Diameter, 25″ Diameter

Material

Steel

CAD Files

3d View
